Optimal Control

This repository contains files, that implements optimal control problems. Optimal control describes the following problem: For a function $f: \mathbb{R}^n \times \mathbb{R}^m \rightarrow \mathbb{R}^n$ and some function $\alpha:[0,\infty) \rightarrow \mathbb{R}^m$ called control we consider an ODE: \(\begin{cases} \dot{x}(t) = f(x(t), \alpha(t)), \\ x(0) = x_0. \end{cases}\)

We want to find a control $\alpha$ in some set$\mathcal{A} \subset \{ \alpha:[0,\infty) \rightarrow \mathbb{R}^m | \ \alpha \text{ is measurable} \}$ (often, $\mathcal{A}$ is just a restriction of the image of the $\alpha$), such that, for some cost functions $r:\mathbb{R}^n \times \mathbb{R}^m \rightarrow \mathbb{R}$ and $g:\mathbb{R}^n \rightarrow \mathbb{R}$, we minimize the functional $P$, defined as: \(P[\alpha] = \int_0^T r(x_\alpha(t), \alpha(t)) dt + g(x(T))\) ($x_\alpha$ is the solution of the ODE, $T$ is allowed to be infinite). Details can be found here:

Rocket Car

Rocket car

This example is analytically solvable, but it’s a good starting point to get an intuition for the situation, especially if we have $\mathcal{A} = {\alpha:(0, \infty) \rightarrow [-1,1] | \ \alpha \text{ is measurable} }$. In these cases the optimal solutions are so called bang bang controls, i.e. we have $\text{im}(\alpha_{\text{ opt}}) \subset \{-1,0,1\}$ (which often is correspondent to putting some switch on to the fullest).

In the example we have given a car on the real number line with a starting point and a starting velocity and two rockets attached on both ends of the car. Both these rockets can be turned on and we can control the car with them. This can be interpreted as an optimal control problem. The derivation of the analytical solution is given in the script by Evans on p.10. It is implemented in rocket_car.py.

Moon Lander

Moon lander

In this example the height and velocity of a spacecraft close to the moon is given. Due to gravity it accelerates towards the surface of the astronomical body. Intuitively it is clear that we have to fire the rockets at the bottom of the carrier at some point to guarantee a smooth landing. We also want to minimise fuel use. Here, we have to be careful (this makes it a nice example for optimal control problems): Using up fuel decreases the mass of the rocket which obviously has an impact on the ODE governing its position and velocity. The details of the problem are extensively discussed in Evans script on p.55. We first discretize the problem and thereafter use classic constrained nonlinear optimization techniques to solve it, namely sequential quadratic programming (SQP). The example is implemented in moon_lander.py.

Inventory Control

If we have a warehouse with items and a stream of demand for our goods, one might be interested in modeling, how we can minimise ordering and storing costs, while still being able to meet demand. Such a model is described in the Evans script on p.70. We solve it via a Hamilton-Jacobi-Bellman approach. The implementation can be found in inventory_control.py.

Bee population

The reproductive strategy of a population of bees wants to maximise the number of queens at the end of a season. As the population consists of workers and queens, the makeup of the bee society is a control system, which tries to optimise this final number of queens. A mathematical description is given on p.6 of the Evans script. We implement and solve it by a Pontryagin maximum principle approach.
